In the realm of embedded systems, Microchip’s PIC16 series microcontrollers are widely used for their reliability, simplicity, and broad integration into industrial and commercial electronics. However, these microcontrollers often come with protective mechanisms that prevent unauthorized access to their embedded firmware, especially in legacy models like the PIC16C63A. At CIRCUIT ENGINEERING CO.,LTD, we offer advanced solutions to attack Microcontroller PIC16C63A heximal, allowing our clients to crack, decode, and restore valuable program data locked behind layers of secured flash memory.

oferecemos soluções avançadas para atacar o Microcontrolador PIC16C63A Heximal, permitindo que nossos clientes quebrem, decodifiquem e restaurem dados valiosos de programas bloqueados por camadas de memória flash segura. Quando a documentação original é perdida ou você precisa clonar um dispositivo legado para manutenção ou substituição, o acesso ao conteúdo binário original torna-se crítico. Infelizmente, segmentos de EEPROM e flash bloqueados ou criptografados frequentemente dificultam esses esforços. É aí que nosso serviço de ataque a microcontroladores se torna essencial. Utilizamos técnicas especializadas para descriptografar, copiar e extrair o arquivo de programa heximal de microcontroladores protegidos, oferecendo acesso total ao código-fonte original ou à sua forma mais próxima possível.

Why Attack a Protected PIC16C63A?
When original documentation is lost, or you need to clone a legacy device for maintenance or replacement, accessing the original binary content becomes critical. Unfortunately, locked or encrypted EEPROM and flash segments often hinder such efforts. That’s where our microcontroller attack service becomes essential. We use specialized techniques to decrypt, copy, and extract the heximal program file from secured microcontrollers, giving you full access to the original source code or its closest possible form.

Tailored Process for PIC16C63A Firmware Extraction
Here’s how we approach each project involving the PIC16C63A:

1. Device Preparation
We begin by identifying the exact chip configuration, including memory layout, protection fuses, and voltage thresholds. The PIC16C63A typically features code protection bits that prevent straightforward access, so our team uses non-invasive and semi-invasive hardware probing techniques to prepare the device for data access.

2. Protection Bypass
The core of the process involves unlocking the protected flash memory. Depending on the device’s revision, we may exploit known vulnerabilities or employ glitching and fault injection techniques to bypass the microcontroller’s security. This phase is where we essentially attack the microcontroller PIC16C63A heximal at the hardware level.

3. Memory Dump
Once the protection is bypassed, we directly interface with the chip’s memory and dump the firmware, EEPROM data, and other critical content. This archived binary is often saved as a .hex file, representing the raw machine code the device runs.

4. Reverse Engineering (Optional)
If required, we can take the extracted heximal firmware and decode it into more readable assembly language or even decompiled C source code, making it easier to analyze or repurpose for your application.

5. Validation and Cloning
The final phase involves testing the duplicated program file by reprogramming it into a compatible blank microcontroller, ensuring it operates identically to the original. This allows you to clone, backup, or modify the firmware for future development or troubleshooting.

हम मेमोरी लेआउट, सुरक्षा फ़्यूज़ और वोल्टेज थ्रेसहोल्ड सहित सटीक चिप कॉन्फ़िगरेशन की पहचान करके शुरू करते हैं। PIC16C63A में आमतौर पर कोड सुरक्षा बिट्स होते हैं जो सीधे एक्सेस को रोकते हैं, इसलिए हमारी टीम डिवाइस को डेटा एक्सेस के लिए तैयार करने के लिए गैर-आक्रामक और अर्ध-आक्रामक हार्डवेयर जांच तकनीकों का उपयोग करती है।, प्रक्रिया के मूल में संरक्षित फ्लैश मेमोरी को अनलॉक करना शामिल है। डिवाइस के संशोधन के आधार पर, हम ज्ञात कमजोरियों का फायदा उठा सकते हैं या माइक्रोकंट्रोलर की सुरक्षा को बायपास करने के लिए गड़बड़ और दोष इंजेक्शन तकनीकों को नियोजित कर सकते हैं। यह वह चरण है जहाँ हम अनिवार्य रूप से हार्डवेयर स्तर पर माइक्रोकंट्रोलर PIC16C63A हेक्सिमल पर हमला करते हैं।, एक बार सुरक्षा को बायपास कर देने के बाद, हम सीधे चिप की मेमोरी से जुड़ते हैं और फ़र्मवेयर, EEPROM डेटा और अन्य महत्वपूर्ण सामग्री को डंप करते हैं। यह संग्रहीत बाइनरी अक्सर .hex फ़ाइल के रूप में सहेजी जाती है, जो डिवाइस द्वारा चलाए जाने वाले कच्चे मशीन कोड का प्रतिनिधित्व करती है।

Attack Microcontroller PIC16C63A protective memory and readout heximal of MCU PIC16C63A flash memory, microprocessor PIC16C63A unlocking process will normally start from chip surface decapsulation;

Attack Microcontroller PIC16C63A protective memory and readout heximal of MCU PIC16C63A flash memory, microprocessor PIC16C63A unlocking process will normally start from chip surface decapsulation

Devices included in this data sheet:

PIC16C7X Peripheral Features:

· Timer0: 8-bit timer/counter with 8-bit prescaler

· Timer1: 16-bit timer/counter with prescaler can be incremented during SLEEP via external

PIC16CXX Microcontroller Core Features:

· High performance RISC CPU

· Only 35 single word instructions to learn

· All single cycle instructions except for program branches which are two cycle

· Operating speed: DC – 20 MHz clock input

DC – 200 ns instruction cycle

· 4 K x 14 words of Program Memory,

192 x 8 bytes of Data Memory (RAM)

· Interrupt capability

· Eight-level deep hardware stack

· Direct, indirect and relative addressing modes

· Power-on Reset (POR)

· Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation

· Programmable code protection

· Power-saving SLEEP mode crystal/clock

· Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

· Capture, Compare, PWM modules

– Capture is 16-bit, max. resolution is 200 ns

– Compare is 16-bit, max. resolution is 200 ns

– PWM max. resolution is 10-bit

· 8-bit multichannel Analog-to-Digital converter

· Synchronous Serial Port (SSP) with SPITM and I2CTM

· Universal Synchronous Asynchronous Receiver Transmitter (USART/SCI)

· Parallel Slave Port (PSP), 8-bits wide with external RD, WR and CS controls when Attack Microcontroller

· Brown-out detection circuitry for Brown-out Reset (BOR) Pin Diagram: PDIP, Windowed CERDIP

· Selectable oscillator options

· Low power, high speed CMOS EPROM technology

· Wide operating voltage range: 2.5V to 5.5V

· High Sink/Source Current 25/25 mA

· Commercial, Industrial and Automotive temperature ranges

· Low power consumption:

– < 5 mA @ 5V, 4 MHz

– 23 mA typical @ 3V, 32 kHz

– < 1.2 mA typical standby current

Additional Device Support: PIC16CE625 and Beyond
In addition to the PIC16C63A, we also offer cracking and firmware duplication services for other secured MCUs like the PIC16CE625. These chips include embedded security features similar to the C63A and require precise techniques to unlock safely.
