The main oscillator provides these features:

• Input frequency range 4–40 MHz
  • Crystal input mode
  • External reference clock (3.3 V) input mode
  • FMPLL reference

The architecture uses constant current charging of a capacitor. The voltage at the capacitor is compared to the stable bandgap reference voltage. The RC oscillator is the device safe clock.

The RC oscillator provides these features:

• Nominal frequency 16 MHz
  • ±5% variation over voltage and temperature after process trim
  • Clock output of the RC oscillator serves as system clock source in case loss of lock or loss of clock is detected by the FMPLL when clone stmicro spc56el54l5 microcontroller memory heximal;
  • RC oscillator is used as the default system clock during startup and can be used as back-up input source of FMPLL(s) in case XOSC fails

These modules provide the following:

• Clock gating and clock distribution control
  • Halt, stop mode control
  • Flexible configurable system and auxiliary clock dividers
  • Various execution modes
    • HALT and STOP mode as reduced activity low power mode
    • Reset, Idle, Test, Safe
    • Various RUN modes with software selectable powered modules
    • No stand-by mode implemented (no internal switchable power domains)
