Secured Microprocessor STM32F042C6 Flash Code Extraction will needs to crack stm32f042c6 mcu security fuse bit by focus ion beam, and then dump embedded heximal file from stm32f042c6 flash memory;

The device has integrated power-on reset (POR) and power-down reset (PDR) circuits. They are always active, and ensure proper operation above a threshold of 2 V.

The device remains in reset mode when the monitored supply voltage is below a specified threshold, VPOR/PDR, without the need for an external reset circuit.

• The POR monitors only the VDD supply voltage. During the startup phase it is required that VDDA should arrive first and be greater than or equal to VDD.
  • The PDR monitors both the VDD and VDDA supply voltages, however the VDDA power supply supervisor can be disabled (by programming a dedicated Option bit) to reduce the power consumption if the application design ensures that VDDA is higher than or equal to VDD.

The device features an embedded programmable voltage detector (PVD) that monitors the VDD power supply and compares it to the VPVD threshold when recovery stm32f042k4 microprocessor firmware. An interrupt can be generated when VDD drops below the VPVD threshold and/or when VDD is higher than the VPVD threshold.

защищенный микропроцессор STM32F042C6 для извлечения флэш-кода должен будет взломать предохранитель безопасности микроконтроллера STM32F042C6 с помощью фокусирующего ионного луча, а затем выгрузить встроенный шестигранный файл из флэш-памяти STM32F042C6;

The interrupt service routine can then generate a warning message and/or put the MCU into a safe state. The PVD is enabled by software.
