Recover STM32F038F6 Microcontroller Heximal Data from its flash memory, the microprocessor stm32f038f6 fuse bit will be cracked by focus ion beam technique, and then replicating firmware to new mcu stm32f038f6 for functions cloning;
· Sleep mode
In Sleep mode, only the CPU is stopped. All peripherals continue to operate and can wake up the CPU when an interrupt/event occurs.
· Stop mode
Stop mode achieves very low power consumption while retaining the content of SRAM and registers. All clocks in the 1.8 V domain are stopped, the PLL, the HSI RC and the HSE crystal oscillators are disabled.
The device can be woken up from Stop mode by any of the EXTI lines. The EXTI line source can be one of the 16 external lines, RTC, I2C1 or USART1. USART1 and I2C1 peripherals can be configured to enable the HSI RC oscillator so as to get clock for processing incoming data when attacking stm32f038e6 microprocessor secured flash memory.
восстановить гексимальные данные микроконтроллера STM32F038F6 из его флэш-памяти, бит предохранителя микропроцессора STM32F038F6 будет взломан методом фокусировки ионного луча, а затем реплицирует прошивку на новый микроконтроллер STM32F038F6 для клонирования функций;
System clock selection is performed on startup, however the internal RC 8 MHz oscillator is selected as default CPU clock on reset. An external 4-32 MHz clock can be selected, in which case it is monitored for failure. If failure is detected, the system automatically switches back to the internal RC oscillator.
A software interrupt is generated if enabled. Similarly, full interrupt management of the PLL clock entry is available when necessary (for example on failure of an indirectly used external crystal to break stm32f038c6 microprocessor locked flash memory, resonator or oscillator). Several prescalers allow the application to configure the frequency of the AHB and the APB domains. The maximum frequency of the AHB and the APB domains is 48 MHz.
