Copy IC DSP TMS320LF2401AVFA Flash

We can Copy IC DSP TMS320LF2401AVFA Flash, please view below IC DSP TMS320LF2401AVFA features for your reference:

High-Performance Static CMOS Technology

− 25-ns Instruction Cycle Time (40 MHz)

− 40-MIPS Performance

− Low-Power 3.3-V Design Based on TMS320C2xx DSP CPU Core

− Code-Compatible With F243/F241/C242

− Instruction Set and Module Compatible With F240 Flash (LF) and ROM (LC) Device Options

− LF240xA: LF2407A, LF2406A, LF2403A, LF2402A

− LC240xA: LC2406A, LC2404A, LC2403A, LC2402A

On-Chip Memory

− Up to 32K Words x 16 Bits of Flash EEPROM (4 Sectors) or ROM

− Programmable “Code-Security” Feature for the On-Chip Flash/ROM

− Up to 2.5K Words x 16 Bits of Data/Program RAM

− 544 Words of Dual-Access RAM

− Up to 2K Words of Single-Access RAM Boot ROM (LF240xA Devices)

− SCI/SPI Bootloader Up to Two Event-Manager (EV) Modules (EVA and EVB), Each Includes:

− Two 16-Bit General-Purpose Timers

− Eight 16-Bit Pulse-Width Modulation (PWM) Channels Which Enable:

− Three-Phase Inverter Control

− Center- or Edge-Alignment of PWM Channels

− Emergency PWM Channel Shutdown With External PDPINTx Pin

− Programmable Deadband (Deadtime) Prevents Shoot-Through Faults

− Three Capture Units for Time-Stamping of External Events

− Input Qualifier for Select Pins

− On-Chip Position Encoder Interface Circuitry to faciliate the process of IC Cloning

− Synchronized A-to-D Conversion

− Designed for AC Induction, BLDC, Switched Reluctance, and Stepper Motor Control

− Applicable for Multiple Motor and/or Converter Control

External Memory Interface (LF2407A)

− 192K Words x 16 Bits of Total Memory:

64K Program, 64K Data, 64K I/O Watchdog (WD) Timer Module 10-Bit Analog-to-Digital Converter (ADC)

− 8 or 16 Multiplexed Input Channels

− 500-ns MIN Conversion Time

− Selectable Twin 8-State Sequencers Triggered by Two Event Managers Controller Area Network (CAN) 2.0B Module (LF2407A, 2406A, 2403A)

Serial Communications Interface (SCI)

16-Bit Serial Peripheral Interface (SPI)

(LF2407A, 2406A, LC2404A, 2403A)

Phase-Locked-Loop (PLL)-Based Clock

Generation

Up to 40 Individually Programmable,

Multiplexed General-Purpose Input / Output (GPIO) Pins

Up to Five External Interrupts (Power Drive

Protection, Reset, Two Maskable Interrupts) Power Management:

− Three Power-Down Modes

− Ability to Power Down Each Peripheral Independently

Real-Time JTAG-Compliant Scan-Based

Emulation, IEEE Standard 1149.1† (JTAG)

Development Tools Include:

− Texas Instruments (TI) ANSI C Compiler, Assembler/ Linker, and Code Composer Studio Debugger

− Evaluation Modules

− Scan-Based Self-Emulation (XDS510)

− Broad Third-Party Digital Motor Control Support Package Options

− 100-Pin LQFP PZ (2406A, LC2404A)

− 64-Pin TQFP PAG (LF2403A, LC2403A, LC2402A)

− 64-Pin QFP PG (2402A)

Extended Temperature Options (A and S)

− A: − 40°C to 85°C

− S: − 40°C to 125°C
