Attack MCU ATmega162 can help engineer to find out the location of security fuse bit then use laser cutting to remove it, and reset the status of Microcontroller from locked to unlocked;



Features

· High-performance, Low-power AVR® 8-bit Microcontroller

· Advanced RISC Architecture

– 131 Powerful Instructions – Most Single-clock Cycle Execution

– 32 x 8 General Purpose Working Registers

– Fully Static Operation

– Up to 16 MIPS Throughput at 16 MHz when Attack MCU

– On-chip 2-cycle Multiplier



Non-volatile Program and Data Memories

– 16K Bytes of In-System Self-programmable Flash Endurance: 10,000 Write/Erase Cycles

– Optional Boot Code Section with Independent Lock Bits

In-System Programming by On-chip Boot Program

True Read-While-Write Operation

– 512 Bytes EEPROM

Endurance: 100,000 Write/Erase Cycles

– 1K Bytes Internal SRAM

– Up to 64K Bytes Optional External Memory Space after Attack MCU



8-bit

Microcontroller

with 16K Bytes

In-System

– Programming Lock for Software Security

JTAG (IEEE std. 1149.1 Compliant) Interface

– Boundary-scan Capabilities According to the JTAG Standard

– Extensive On-chip Debug Support before Attack MCU

– Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface

Peripheral Features

– Two 8-bit Timer/Counters with Separate Prescalers and Compare Modes

– Two 16-bit Timer/Counters with Separate Prescalers, Compare Modes, and

Capture Modes

– Real Time Counter with Separate Oscillator

– Six PWM Channels

– Dual Programmable Serial USARTs if Attack MCU

– Master/Slave SPI Serial Interface

– Programmable Watchdog Timer with Separate On-chip Oscillator

– On-chip Analog Comparator

Special Microcontroller Features

– Power-on Reset and Programmable Brown-out Detection

– Internal Calibrated RC Oscillator

– External and Internal Interrupt Sources after Attack MCU

– Five Sleep Modes: Idle, Power-save, Power-down, Standby, and Extended Standby

I/O and Packages

– 35 Programmable I/O Lines

– 40-pin PDIP, 44-lead TQFP, and 44-pad MLF

Operating Voltages

– 1.8 – 5.5V for ATmega162V

– 2.7 – 5.5V for ATmega162

Speed Grades



Programmable Flash

ATmega162

ATmega162V if Attack MCU



– 0 – 8 MHz for ATmega162V (see Figure 113 on page 265)

– 0 – 16 MHz for ATmega162 (see Figure 114 on page 265)
