Recover Microcontroller PIC16C641 Eeprom

We can Recover Microcontroller PIC16C641 Eeprom, please view the Microcontroller PIC16C641 features for your reference:

High Performance RISC CPU:

· Only 35 instructions to learn

· All single-cycle instructions (200 ns), except for program branches which are two-cycle when Recover Microcontroller

· Operating speed:

– DC – 20 MHz clock input

– DC – 200 ns instruction cycle

· Interrupt capability

· 8-level deep hardware stack

· Direct, Indirect and Relative addressing modes can help to Break IC PIC12F609 Heximal

Peripheral Features:

· Up to 33 I/O pins with individual direction control

· High current sink/source for direct LED drive

· Analog comparator module with:

– Two analog comparators

– Programmable on-chip voltage reference (VREF) module

– Programmable input multiplexing from device inputs and internal voltage reference

– Comparator outputs can be output signals

· Timer0: 8-bit timer/counter with 8-bit programmable prescaler

Special Microcontroller Features:

· Power-on Reset (POR)

· Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Brown-out Reset

· Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation

· Programmable code protection will tamper the resistance of Break IC PIC12F615 Software

· Power saving SLEEP mode

· Serial in-circuit programming (via two pins)

· Four user programmable ID locations

· Program Memory Parity Error checking circuitry with Parity Error Reset (PER) to Crack MCU

· CMOS Technology:

· Low-power, high-speed CMOS EPROM technology

· Fully static design

· Wide operating voltage range: 3.0V to 6.0V

· Commercial, Industrial and Automotive temperature ranges

· Low power consumption

– < 2.0 mA @ 5.0V, 4.0 MHz

– 15 µA typical @ 3.0V, 32 kHz

– < 1.0 µA typical standby current @ 3.0V
