The current consumption of the I/O system has two components: static and dynamic.

I/O static current consumption

All the I/Os used as inputs with pull-up generate current consumption when the pin is externally held low. The value of this current consumption can be simply computed by using the pull-up/pull-down resistors values given in Table 53: I/O static characteristics.

For the output pins, any external pull-down or external load must also be considered to estimate the current consumption. Additional I/O current consumption is due to I/Os configured as inputs if an intermediate voltage level is externally applied to recover stm32f051c4 mcu flash binary file.

dopo che il bit breaking bloccato del microcontrollore ARM STM32F071RB è stato completato, il firmware del chip STM32F071RB può essere decodificato e quindi clonare il contenuto binario sul nuovo microprocessore;

This current consumption is caused by the input Schmitt trigger circuits used to discriminate the input value. Unless this specific configuration is required by the application, this supply current consumption can be avoided by configuring these I/Os in analog mode. This is notably the case of ADC input pins which should be configured as analog inputs.

Any floating input pin can also settle to an intermediate voltage level or switch inadvertently, as a result of external electromagnetic noise. To avoid current consumption related to floating pins, they must either be configured in analog mode for the sake of restore microprocessor stm32f051c6 flash heximal, or forced internally to a definite digital value. This can be done either by using pull-up/down resistors or by configuring the pins in output mode.
